    CHB402

    Measurement accuracy: ±0.5%F±1

    Sampling rate: 2 times / sec

    Adjustment mode: Intelligent PID regulation, according to different PID parameters can be composed of P (binary), PI, PD, PID regulation

    Output mode(customizable):crelay contact AC220V / 5A, level signal 12V /20mA, zero crossing trigger thyristor, analog quantity can be customized

    Alarm mode: upper limit (or upper deviation), lower limit (or lower deviation)
    With manual control function, and manual automatic undisturbed switching

    Power supply(customizable): 220 VAC, ± 10% / 50-60Hz

    Power consumption: ≤ 5W

    Ambient temperature: 0-50℃





    Type

    CHB402

    Power Supply

    AC220V / 24VDC / 380VAC

    Input

    K(-50~+ 1300℃),E(0~800℃),

    Cu50(-50~+150℃),PT100(-200~+600)

    Output

    RELAY / SSR / 4~20mA / 0-10V

    Accuracy of Measurement

    ±0.5%

    Operating temperature

    0-50℃

    Compensating error of cold side

    ±2℃(the software corrects the data for 0-50℃ fluctuations in temperature )

    Control Mode

    Adopt industrial and PID Parameters of

    Control System,Temperature Control,

    responsible faster,Start modulation smaller,

    accuracy higher than troditionalPID




    Dimensions:

    48*48mm*86mm

    Accuracy:

    0.5

    Input:

    K/E/J/R/S/B/N/T/PT100/CU500 adjustable

    Output:

    SSR

    Alram:

     ALM1, ALM2

    Control mode:

    PID,ON/OFF

    Power Supply:

    180V-220V AC 50hz

    Working Environment

    Temperature 0°C~50°C RH:35%~85%

    Weight:

    210g








    Hot Tags: CHB402, manufacturers, suppliers, factory, Customized



    Type

    CHB402

    Power Supply

    AC220V / 24VDC / 380VAC

    Input

    K(-50~+ 1300℃),E(0~800℃),

    Cu50(-50~+150℃),PT100(-200~+600)

    Output

    RELAY / SSR / 4~20mA / 0-10V

    Accuracy of Measurement

    ±0.5%

    Operating temperature

    0-50℃

    Compensating error of cold side

    ±2℃(the software corrects the data for 0-50℃ fluctuations in temperature )

    Control Mode

    Adopt industrial and PID Parameters of

    Control System,Temperature Control,

    responsible faster,Start modulation smaller,

    accuracy higher than troditionalPID




    Dimensions:

    48*48mm*86mm

    Accuracy:

    0.5

    Input:

    K/E/J/R/S/B/N/T/PT100/CU500 adjustable

    Output:

    SSR

    Alram:

     ALM1, ALM2

    Control mode:

    PID,ON/OFF

    Power Supply:

    180V-220V AC 50hz

    Working Environment

    Temperature 0°C~50°C RH:35%~85%

    Weight:

    210g
