The AH3-2 Time Relay is a versatile and reliable timing device designed for precise time-delay control in a wide range of industrial and commercial applications. Known for its accuracy, durability, and user-friendly design, the AH3-2 is widely used in motor control, automation systems, lighting control, and other electrical setups that require timed operations.
High Precision Timing
The AH3-2 Time Relay offers accurate and adjustable timing control, with a wide range of time settings to meet various operational requirements.
Multiple Timing Modes
It supports multiple timing functions, including On-Delay, Off-Delay, and Interval timing, making it suitable for diverse applications.
Compact and Space-Saving Design
The relay features a compact design, allowing for easy installation in control panels, electrical enclosures, and DIN rail systems.
Durable Construction
Built with high-quality materials, the AH3-2 is designed to withstand harsh industrial environments, ensuring long-term reliability and performance.
Easy Installation and Operation
The relay is equipped with user-friendly terminals and clear labeling, simplifying installation and configuration.
LED Status Indicator
An integrated LED indicator provides real-time visual feedback on the relay's operational status, aiding in quick diagnostics and troubleshooting.
The AH3-2 Time Relay is suitable for a wide range of applications, including:
Motor Control: Delays the start or stop of motors to prevent damage from frequent switching.
Lighting Systems: Automates the switching of lighting for energy efficiency and convenience.
Industrial Automation: Controls the timing of machinery and equipment in production lines.
HVAC Systems: Manages the operation of heating, ventilation, and air conditioning systems.
Pump Control: Regulates the timing of pumps in water treatment, irrigation, and other systems.
Conveyor Systems: Synchronizes the operation of conveyor belts with other machinery.
Rated Voltage: AC/DC options available
Time Range: Adjustable from 0.1 seconds to several hours (model-dependent)
Contact Capacity: Supports resistive and inductive loads
Operating Temperature: -10°C to +55°C
Protection Rating: IP20 (indoor use)
Mounting: DIN rail or panel mount options
Model | AH3-2 | Contact capacity | AC 250V 3A |
Contact | Two delay contacts | Dimension | 50*40*82cm |
Installation | With base or by 35mm rail | Electrical life | ≥105 |
voltage | AC 24V/ 220V/ 380V; DC 24V | ||
Operation type | power On delay | ||
Delay range | SEC: 1,3,6,12,30,60 | ||
Technical Parameter
- Using CMOS IC lower power consumption high reliability and stability
- 15 different time ranges from 0.1 sec to 24 hrs available (Each time range the product is individually customized)
- Power Supply
Non universal voltage: AC(V) 12 ,24, 110, 220 ,240 50/60Hz , DC(V) 12, 24
- Output Contacts rated 5A at 120/240 VAC and 30 VDC, resistive load.
- Front panel mounted with a P3G-08/US-08 Socket ).
- On-Delay version
- One delayed contact (SPDT Relay) + One instantaneous contact (SPDT Relay) Output
- Large and easy to read dial shows decimal points
- Two Leds provide status indication for ON-OFF operations
