The H3Y-2 Time Relay is a compact and reliable timing device designed for precise time-delay control in various industrial and commercial applications. Known for its accuracy, durability, and ease of use, the H3Y-2 is widely used in motor control, automation systems, and other electrical setups requiring timed operations.
Accurate Timing Control
The H3Y-2 Time Relay provides highly accurate timing with adjustable time ranges, ensuring precise control over delayed operations.
Multiple Timing Modes
It supports various timing functions, including On-Delay and Off-Delay modes, making it versatile for different application requirements.
Compact and Space-Saving Design
The relay's small size allows for easy integration into control panels and electrical enclosures, saving valuable space.
Durable Construction
Built with high-quality materials, the H3Y-2 is designed to withstand harsh industrial environments, ensuring long-term reliability.
Easy Installation and Operation
With user-friendly terminals and clear labeling, the H3Y-2 is simple to install and configure, reducing setup time and effort.
LED Indicator
An integrated LED indicator provides visual feedback on the relay's operational status, aiding in quick diagnostics and troubleshooting.
The H3Y-2 Time Relay is suitable for a wide range of applications, including:
Motor Control: Delays the start or stop of motors to prevent damage from frequent switching.
Lighting Systems: Automates the switching of lighting for energy efficiency and convenience.
Industrial Automation: Controls the timing of machinery and equipment in production lines.
HVAC Systems: Manages the operation of heating, ventilation, and air conditioning systems.
Pump Control: Regulates the timing of pumps in water treatment, irrigation, and other systems.
Rated Voltage: AC/DC options available
Time Range: Adjustable from 0.1 seconds to several hours (model-dependent)
Contact Capacity: Supports resistive and inductive loads
Operating Temperature: -10°C to +55°C
Protection Rating: IP20 (indoor use)
Mounting: DIN rail or panel mount options
Specification
Voltage | DC 12V-48V AC 12V-380V 50/60Hz |
Power Expend | DC 1.0W AC1.0VA |
Contact Output | 2Z 5A220VAC 4Z 3A220VAC |
Insulation Resistance | DC500V 100MΩ |
Dielectric Strength | BCC1500VAC BOC1000VAC |
Operating Temperature | -10℃~50℃ |
Huminity | 35%~85% |
Life | Mech:10^7 Elec:10^3 |
Weight | ≈50g |
Time Range
Rated Time | Time Range | Rated Time | Time Range |
0.5S | 0.05S~0.5S | 0.5m | 0.05~0.5m |
1S | 0.1S~1S | 1m | 0.1m~1m |
5S | 0.5S~5S | 5m | 0.5m~5m |
10S | 0.5S~10S | 10m | 0.5m~10m |
30S | 1.0S~30S | 30m | 1m~30m |
60S | 2.0S~60S | 60m | 2m~60S |
180S | 3m | 180m | 0.1h~10h |
120S | 5.0S~120S | 120m | 0.1h~10h |
Dimension.Bottom View
Product description
Working power: | DC24V;AC24V,220V,380V |
Delay range: | 1s,6s,10s,30s,60s,120s, |
Repeat error: | ≤1% |
Operating mode: | Power-on delay |
Contact shape: | ST6P-2, H3Y-2; two sets of delay contacts |
Contact rating: | 3A AC220V (resistive) |
Dimensions: | 76×50×106mm |
Installation method: | 35mm rail |
